THERMOSTAT DEHUMIDIFIER 10000 CMH

LT- CTD50E

  • Process Airflow: 10000 m3/hr
  • Air Pressure: 270 Pa
  • Heating Power: 69.kW
  • Power Consumption: 80.2 kW

CONTROL TYPE

PLC control



USAGE

Control Temp & Relative Humidity



APPLICATION

Blasting and Painting for shipyard, marine offshore, oil & gas tank, ventilation, paint curing,…

PRODUCT DESCRIPTION

Air-cooled temperature-regulating dehumidifier, steam compression refrigeration cycle, air as a cold (hot) source. It is widely used in aerospace field, civil air defense engineering, purification engineering, subway station, and chemical industry and other places with dehumidification requirements.

FEATURES

  • This machine can dehumidify, heating and cooling
  • Temperature control and accurate rate: 18-30℃ ±1.0℃
  • Energy saving
  • Auto defrost

WORKING PRINCIPLES

Temperature regulating dehumidifier: According to the humidity value set by the user, according to the principle of refrigeration and dehumidification, the relative humidity of the air can be adjusted, and the unit is equipped with outdoor air-cooled condenser. Taking away all the heat through the condenser can prevent the room temperature increase caused by the long-term operation of the dehumidifier.

Model LT-CTD50E
Dehumidifier Capacity 49.2L/H
Refrigerant capacity 78kW
Heating Capacity 69.8kW
Rated Power 27.5kW
Power Supply 380V/50Hz/3Ph
Cooling capacity 80.2 KW
Air circulation 13000 (m3/h)
Refrigerant R407C
ESP 270Pa
Indoor Unit N.W 840KGS
Type of unit Temperature regulating and dehumidifying
Outdoor ambient temperature 18~43 °C
Indoor temperature humidity 18~32°C, 40~90%
Voltage Deviation (V) 5% ± rated voltage








    * Required

    Technical Specification
    Model LT-CTD50E
    Dehumidifier Capacity 49.2L/H
    Refrigerant capacity 78kW
    Heating Capacity 69.8kW
    Rated Power 27.5kW
    Power Supply 380V/50Hz/3Ph
    Cooling capacity 80.2 KW
    Air circulation 13000 (m3/h)
    Refrigerant R407C
    ESP 270Pa
    Indoor Unit N.W 840KGS
    Type of unit Temperature regulating and dehumidifying
    Outdoor ambient temperature 18~43 °C
    Indoor temperature humidity 18~32°C, 40~90%
    Voltage Deviation (V) 5% ± rated voltage
